2022 Kawasaki Mule SX 4x4 XC FI

2022 Kawasaki Mule SX FI 4x4 XC at Dale's Fun Center, Victoria, TX 77904

‹ ›

Reset Zoom

‹ › - +

‹ ›

Stock Photos - Actual Images Coming Soon

This vehicle is getting attention.
559 people have recently viewed it.

Pre-Order Now!

Hi, my name is and I'm interested in this 2022 Kawasaki Mule SX FI 4x4 XC . I'm in the area and you can reach me at or by phone at

	Is this unit still available?
	What payment terms are available?
	When can I test ride this unit?

Available Color

Firecracker Red

Details

Status:
New
Vehicle:
2022 Kawasaki Mule SX 4x4 XC FI
Model Number:
KAF400RNFNN
Color:
Firecracker Red
Location:
Dale's Fun Center, Victoria, TX 77904
Warranty:
Manufacturer's w/ Extended Available

Specifications

BRAKES

Front Brake Type:
Sealed Hydraulic Drum
Rear Brake Type:
Sealed Hydraulic Drum

DRIVE LINE

Differential Lock Location:
Rear
Driveline Type:
Selectable 4X2 / 4X4
Limited Slip Differential Location:
Front
Number Of Driveline Modes:
2
Rear Unlocking Differential:
Yes

ENGINE

Bore (in):
3.23
Bore (mm):
82
Carburetion Type:
Fuel Injected
Compression Ratio:
8.6
Cooling:
Air / Fan
Cylinders:
1
Displacement (cc):
401
Displacement (ci):
24.5
Engine Stroke:
4-Stroke
Engine Type:
Single-Cylinder
Fuel Injector Size (mm):
23
Fuel Injector:
Yes
Fuel Requirements:
Regular
Fuel Type:
Gas
Speed Governor:
Yes
Starter:
Electric
Stroke (in):
2.99
Stroke (mm):
76
Torque (Ft Lbs):
21.4
Torque (Nm):
29
Torque RPM:
2400
Valve Configuration:
OHV
Valves Per Cylinder:
2
Valves:
2

EXTERIOR

Bash Plate (Front):
Yes
Body Material:
Plastic
Frame:
Steel
Front Mud Guards:
Yes

INSTRUMENTATION

Fuel Level Warning Type:
Gauge
Temperature Warning Type:
Light

LIGHTS

Type:
Halogen

SEATS

Folding:
Yes
Number Of Rows:
1
Number Of Seats:
2
Seat Material:
Vinyl
Seat Type:
Bench

STEERING

Steering Control:
Steering Wheel
Steering Type:
Rack & Pinion

STORAGE

Bed Capacity (kgs.):
181
Bed Capacity (lbs.):
399
Bed Height (in):
9.6
Bed Height (mm):
243.8
Bed Length (in):
35.6
Bed Length (mm):
904.2
Bed Volume (ft3):
8.1
Bed Volume (m3):
0.2
Bed Width (in):
40.9
Bed Width (mm):
1038.9
Cargo Bed Material:
Steel
Cargo Bed Tilt:
Yes
Integral Tie-Down Hooks:
Yes
Number Of Cupholders:
2
Rack Rails Location:
Cargo Bed

SUSPENSION

Adjustment Type:
Shock Mounted Adjustment
Front Suspension Type:
McPherson Strut
Front Travel (in):
3.1
Front Travel (mm):
78.7
Number Rear Shock Absorbers:
2
Rear Adjustable Shock / Spring Pre-Load:
Yes
Rear Suspension Type:
Swing Arm
Rear Travel (in):
3.1
Rear Travel (mm):
78.7

TECHNICAL SPECIFICATIONS

Fuel Capacity (gal):
4.2
Fuel Capacity (l):
15.9
Ground Clearance (in):
8.1
Ground Clearance (mm):
205.7
Height (in):
73.4
Height (mm):
1864.4
Length (ft):
8.89
Length (ft/ft):
8
Length (ft/in):
10.7
Length (in):
106.7
Length (mm):
2710.2
Payload Capacity (kgs):
420
Payload Capacity (lbs):
926
Towing Capacity (kgs):
499
Towing Capacity (lbs):
1100
Turning Radius (ft):
11.8
Wet Weight (kg):
491.1
Wet Weight (lbs):
1082.7
Wheelbase (in):
70.1
Wheelbase (mm):
1780.5
Width (in):
52.6
Width (mm):
1336

TRANSMISSION

Hi / Low Range:
Yes
Primary Drive (Engine / Transmission):
Belt
Primary Drive (Front Wheel):
Shaft
Primary Drive (Rear Wheel):
Shaft
Reverse:
Yes
Transmission Type:
Continuously Variable (CVT)

WHEELS & TIRES

Front Tire (Full Spec):
Duro
Front Tire Diameter (in):
26
Front Tire Width:
9
Front Wheel Diameter:
12
Rear Tire (Full Spec):
Duro
Rear Tire Diameter (in):
26
Rear Tire Width:
9
Rear Wheel Diameter:
12
Tire Brand:
Duro
Tube / Tubeless:
Tubeless
Wheels Composition:
Steel
